300W Pulsed Laser Cleaning Machine 5mJ - 15mJ Portable Laser Rust Cleaning Machine

Place of Origin China
Brand Name JPTECH
Certification CE, FDA, IEC 60825-1、UL 61010、RoHS
Model Number GY-FLC300
Minimum Order Quantity 1
Packaging Details wood carton
Delivery Time 7-10 days
Payment Terms ,MoneyGram,Western Union,T/T,L/C
Supply Ability 50sets/month

Contact me for free samples and coupons.

WhatsAPP:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Power 300W Laser Type Pulse
Radiator Air Cooling Cleaning Speed 0-5㎡/h
Cleaning Width >2000mm Function Cleaning Metal Rust Oil Painting
Highlight

Pulsed Laser Cleaning Machine 5mJ

,

300W Pulsed Laser Cleaning Machine

,

15mJ Laser Rust Cleaning Machine

Leave a Message
Product Description

300W Pulse Laser Cleaning Machine 5mJ-15mJ Portable Suitcase Laser Cleaner Metal Rust Remove

I. Product description

Laser cleaning is a new technology based on the interaction of laser and material, which can achieve the effect of removing surface pollution and attachment. Compared with traditional cleaning methods, laser cleaning has the advantages of non-contact, no damage to the substrate, accurate cleaning ," green "environmental protection and on-line, especially suitable for high-speed on-line cleaning in designated areas.

300W Pulsed Laser Cleaning Machine 5mJ - 15mJ Portable Laser Rust Cleaning Machine 0

          The laser cleaning equipment produced by My Company is a new generation of high-tech products for surface treatment, which is easy to install, control and realize automation. Simple operation, power supply, open equipment, can be no chemical reagent, no medium, no dust, no water cleaning, can fit surface cleaning, cleaning surface cleanliness is high, can remove object surface resin, paint, oil stains, dirt, rust, coating, coating and oxidation layer, and the industry is widely used, covering ships, auto repair, rubber mold, high-end machine tools, tracks and environmental protection.



II. Operating environment and related parameters

Operating environment

Content

GY-FLC300ML

Supply voltage

Single phase220V±10%,50/60Hz AC

Power consumption

≤1100W

Working environment temperature

5℃~40℃

Working environment humidity

≤80%

Optical parameters

Average laser power

≥300W

Power instability

<5%

Laser Working Mode

Pulse

Pulse width

13-500ns

Maximum monopulse energy

5mJ-15mJ

Power regulation range(%)

0-100( Gradient Adjustable)

Repeat frequency(kHz)

1-3000(Gradient Adjustable)

Fiber length

5m

Cooling mode

Air cooling



III. Equipment characteristics

  • non-contact cleaning without damaging the matrix of the parts.

  • accurate cleaning, can achieve precise position, accurate size selective cleaning.

  • do not need any chemical cleaning liquid, no consumables, safety and environmental protection.

  • simple operation, hand-held or with the manipulator to achieve automatic cleaning.

  • ergonomics design, operating labor intensity greatly reduced.

  • trolley design, with its own moving wheel, easy to move.

  • High cleaning efficiency, save time.

  • laser cleaning system is stable with little maintenance.

IV. Product structure

1) Structure of Cleaning Head

300W Pulsed Laser Cleaning Machine 5mJ - 15mJ Portable Laser Rust Cleaning Machine 1  300W Pulsed Laser Cleaning Machine 5mJ - 15mJ Portable Laser Rust Cleaning Machine 2



2) Overall Dimension

300W Pulsed Laser Cleaning Machine 5mJ - 15mJ Portable Laser Rust Cleaning Machine 3300W Pulsed Laser Cleaning Machine 5mJ - 15mJ Portable Laser Rust Cleaning Machine 4



V. Installation and Application of Laser Cleaning Machine

1)Precautions before use:

  • Check whether the appearance of the product is abnormal and whether the output cable is damaged.

  • Please correctly insert the quick plug according to the label of the control box.

  • Please correctly intervene in the power supply to ensure that the power supply wiring is in good contact.

  • Check and ensure that the cleaning head protects the lens inside and outside without dust.

2)Operation Steps:

  1. Take out the hand-held cleaning gun in the chassis, ensure that the button switch on the handle is loosened, and remove the dust cover of the lens at the front of the laser cleaning gun.

  2. Take out the external power line to energize, turn on the total power switch, open the key switch.

  3. Turn on the start button to power on and initialize the system.

  4. After the system is started, set the laser cleaning parameters on the laser cleaning host interface.

  5. After laser parameters are set, press the laser enable button on the laser cleaning touch screen (before pressing the button, make sure that the button switch on the handle of the handheld head is loosened).

  6. Put on laser protective glasses, aim the head of the gun at the cleaned workpiece, press the switch button on the handle of the finger, and the head of the gun can be cleaned with light (please connect the external control line on the laser cleaning host for automatic use, and switch the laser control through the external control signal).

  7. After use, loosen the switch on the cleaning head, turn off the enable button on the laser cleaning touch screen, press the start button, turn off the key switch, pull down the main power switch, cover the dust cover of the playing mirror, insert the cleaning gun back into the host placing box, and unplug the power plug.
